High-Efficiency MP Blow Molding Machine for 5ml-100L Bottles

High-Efficiency MP Blow Molding Machine for 5ml-100L Bottles
High-Efficiency MP Blow Molding Machine for 5ml-100L Bottles

Large Image :  High-Efficiency MP Blow Molding Machine for 5ml-100L Bottles

Product Details:
Brand Name: MEPER
Certification: CE/ISO9001:2008
Model Number: 100FD
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiate
Packaging Details: Standard Export Package. Wooden Pellet Wooden Case(optional)
Delivery Time: 25-35 Work Days
Payment Terms: L/C,T/T
Supply Ability: 100 Sets Per Month
Contact Now
Detailed Product Description
Total Power: 210 KW Main Screw Diameter: 100 Mm
Plasticizing Capacity: 218 Kg/h Air Pressure: 0.6 - 1 MPa
Product Volume: Max 10 Liter Machine Weight: 15 Ton
Number Of Heads: 3 Sets Cooling Water: 1000 L/min

High-Efficiency MP Blow Molding Machine for 5ml-100L Bottles
Product Overview

The MP100FD Plastic Blow Molding Machine is a highly efficient extrusion blow molding system engineered for producing hollow plastic items ranging from 5ml to 10 liters in volume. This versatile machine is ideal for manufacturing plastic bottles, jars, jerry cans, tool boxes, toys, automotive components, household containers, and industrial packaging solutions.

Designed to accommodate a broad spectrum of raw materials, the MP100FD supports polyethylene (PE), polypropylene (PP), polyvinyl chloride (PVC), polyamide (PA), polycarbonate (PC), polystyrene (PS), and ethylene-vinyl acetate (EVA), providing manufacturers with exceptional flexibility and reliable output.

Key Features
  • High Production Efficiency: Double station design with 3 die heads for multi-cavity production and fast cycle times
  • Wide Material Compatibility: Processes HDPE, LDPE, PP, PVC, PA, PC, PS, and EVA
  • Intelligent Control System: PLC and computer-based automatic control with memory for 40 mold configurations
  • Energy Saving Design: Servo and hydraulically optimized system with stable heating zones
  • Reliable Mechanical Structure: Sturdy toggle clamping system with linear guide rails
Technical Specifications
Model MP100FD
Maximum Product Volume 10 liters
Compatible Materials PE, PP, PVC, PA, PC, PS, EVA
Number of Heads 3 sets
Dimensions (W×L×H) 3.5 × 5.6 × 2.65 meters
Weight 15 tons
Clamping Force 200 KN
Mold Opening Stroke 240-640 mm
Maximum Mold Size 700 × 420 mm
Main Screw Diameter 100 mm
Auxiliary Screw Diameter 75 mm
Plasticizing Capacity 218 kg/hour
Power Consumption 210 KW
Air Pressure 0.6-1 MPa
Air Consumption 1.2 m³/minute
Cooling Water Flow 1000 liters/minute
Applications
  • Packaging Industry: Detergent, chemical, cosmetic, and lubricant bottles
  • Food & Beverage: Juice bottles, water containers, sauce bottles
  • Industrial Products: Jerry cans, tool boxes, plastic drums
  • Household Products: Chairs, storage containers, plastic toys
  • Automotive Parts: Air ducts, reservoir tanks, technical hollow parts
Frequently Asked Questions
What is the brand and model of the Plastic Bottle Blow Molding Machine?
The machine is branded MEPER and the model number is 100FD.
Where is the Plastic Bottle Blow Molding Machine manufactured?
This machine is made in China.
What certifications does the MEPER 100FD Plastic Bottle Blow Molding Machine have?
The machine is certified with CE and ISO9001:2008.
What is the minimum order quantity and price terms for this machine?
The minimum order quantity is 1 set, and the price is negotiable.
What are the packaging and delivery details for the Plastic Bottle Blow Molding Machine?
The machine is packaged in a standard export package with an optional wooden pellet or wooden case. Delivery time is between 25-35 work days.
What payment terms are accepted for purchasing the MEPER 100FD machine?
Payment can be made via L/C (Letter of Credit) or T/T (Telegraphic Transfer).
What is the supply capacity of MEPER for the Plastic Bottle Blow Molding Machine?
MEPER can supply up to 100 sets per month.
