5 Gallon / 3 Gallon Blow Molding Equipment Three Layer 100mm Screw Diameter

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  5 Gallon / 3 Gallon Blow Molding Equipment Three Layer 100mm Screw Diameter

Product Details:
Place of Origin: China
Brand Name: Meper
Certification: ISO
Model Number: MP
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Price negotiation
Packaging Details: Standard Export Package
Delivery Time: 50 work days
Payment Terms: L/C, T/T
Supply Ability: 100 sets per month
Detailed Product Description
Product: Three Layer 5 Gallon Or 3gallon Feature: Three Layer
Brand: MEPER USE: Blow Machine
Capacity: 5 Gallon Or 3gallon
High Light:

fully automatic blow moulding machine

,

blow molding equipment

Three Layer 5 gallon or 3gallon Fully Automatic Blow Moulding Machine MP100FD



Three lay

Out layer virgin material

Middle layer recycle material

Inner layer virgin material



European machine quality  and China machine price.



Standard Features:

Auto Lubrication

Water Cooled Modular Blow Pin

Hot Wire Cutting

Positioning Hole For Quick Mold Change

Adjustable Die head

Linear Transducer

FRL(Filter Regulator Lubricator) for Pneumatic

Proportional Hydraulic System fro better control

Swing and Adjustable Extrusion Platform







Parameters MP100FD
Material PE PP PVC PA…
Max container capacity 5 gallon, 3 gallon
Number of die 1,2,3,4,6
Machine Dimension(LxWxH) 5.2x6.5x3.1m
Total weight 15ton
Clamping force 200kN
Platen openning stokes 240-640mm
Toggle stokes 720mm
Max mould size(WxH) 670x430mm
Screw diameter 100mm
Screw L/D ratio 26 L/D
(HDPE) Plasticizing capacity 218kg/h
Screw heating zone 4 zone
Screw heating power 17kw
Screw fan power 0.14kw
Extrusion motor power 55kw
Die head heating zone 10 zone
Power of die heating 12.8kw
Total power of machine 136kw
Power of oil pump motor 31kw
Air pressure 0.6-0.8 Mpa
Average energy consumption 95kw
Consumption compression air 3.2m³/min
Consumption cooling water 110L/min
