Product Description:
The Automatic Blow Moulding Machine is fully customizable in terms of color, allowing you to choose a color that fits your branding and aesthetic preferences. Additionally, this machine comes with a one-year warranty, providing peace of mind and ensuring that any issues that arise are promptly taken care of.
This water bottle blow molding machine is designed to be easy to use and operate, with intuitive controls that make it simple to produce high-quality bottles consistently. The machine is also designed with durability in mind, ensuring that it can withstand the rigors of continuous use without breaking down or experiencing any issues.
If you are looking for a reliable and efficient custom blow molding machine, the Automatic Blow Moulding Machine is an excellent choice. With its extrusion blow molding technology, four cavities, and customizable features, this machine is perfect for high-volume production of milk bottles and other packing bottles. And with its one-year warranty, you can be confident that it will provide consistent performance and reliability for years to come.
Technical Parameters:
| PARAMETERS |
MP80FD φ80 |
| SPECIFICATIONS |
| material |
PE |
| MAX container capacity L |
10 |
| number of die Set |
1,2 |
| machine dimension(L×W×H) M |
3.4×5.6×2.36 |
| total weight Ton |
14 |
| CLAMPING |
| clamping force KN |
150 |
| platen opening strokes mm |
240-640 |
| toggle stroke mm |
400 |
| Max mould size(W×H) mm |
580×470 |
| EXTRUDER UNIT |
|
| screw diameter mm |
80 |
| screw L/D ratio L/D |
24 |
| (HDPE)plasticizing capacity kg/h |
100 |
| screw heating zone zone |
4 |
| screw heating power kw |
15.85 |
| fan power kw |
0.28 |
| extruder driving power kw |
30 |
| DIE HEAD |
|
| die head heating zone zone |
3 |
| power of die heating kw |
10 |
| ENERGY-CONSUMPTION |
|
| power of the electric motor kw |
29 |
| air pressure Mpa |
0.6-0.8 |
| total power of machine kw |
85.13 |
| average energy consumption kw |
42 |
| compression air consumption m3/min |
1.2 |
| cooling water consumption L/minv |
80 |
Applications:
This Automatic Blow Moulding Machine has a variety of applications and scenarios. Firstly, it can be used in the production of water bottle blow molding machine. The machine has an automatic operation, making it easy to use and efficient. Secondly, it can be used in the production of 4 cavity blow moulding machines. The machine is designed to produce high-quality products in a short period of time. Lastly, it can be used in the production of 5 gallon blow molding machines. The machine is perfect for large-scale production and is capable of producing high-quality products.
The MEPER MP75AE Automatic Blow Moulding Machine is perfect for companies looking to improve their production speed and efficiency. Its extrusion blow molding machine allows for high-quality products to be produced with ease. The contactor used in this machine is Schneider, ensuring its reliability and durability. This machine is applicable for HDPE, LDPE, and PP materials, making it versatile and flexible.
Support and Services:
The Automatic Blow Moulding Machine is a high-tech piece of equipment used in the manufacturing of plastic bottles and containers. Our company offers comprehensive technical support and services for this product to ensure optimal performance and efficiency.
Our team of experienced technicians is available to provide installation, training, and maintenance services for the Automatic Blow Moulding Machine. We understand the importance of minimizing downtime and maximizing production, which is why we offer timely and efficient repair services to keep your machine running smoothly.
In addition, we offer software updates and upgrades to keep your machine up-to-date with the latest technology and improve its overall performance. Our customer service team is also available to answer any questions or concerns you may have about the product or its operation.
