Product Description:
The MP plastic blow molding machine is the perfect solution for processing plastic hollow products with high molecular structure. This machine is specifically designed for producing hollow products ranging from 5 milliliters to 100 liters in size. The various products that can be produced with this machine include bottles, pots, jars, barrels, toys, tool boxes, bed boards, desk boards, chairs, and auto parts.
The MP plastic blow molding machine is highly flexible and can blow different materials such as PE, PP, PVC, PA, PC, PS and EVA. Additionally, it provides the perfect process for working with these materials, ensuring optimal results every time. No matter what type of plastic hollow product you need to produce, the MP plastic blow molding machine provides the precision and flexibility you need.
Features:
The extruding device of this machine is equipped with a variable frequency motor that allows for changes in screw rotation during the blowing process. A screw with a high slenderness ratio can be utilized for processing various materials, thanks to its strong plasticizing ability, and its large production capacity is associated with low energy consumption. The barrel features a resistance heater that is computer controlled and enables quick, stable, and uniform heating.
The combined extrusion system can accommodate different heads for producing products with view stripes or double layers. This feature, paired with the first paragraph's slenderness ratio, allows for a diverse range of materials to be processed.
The mould clamping device is designed with vertical compression, three pilot posts, big beam arms, linear guides, a cylinder spindle, and a double working station, which facilitates fast and stable movement. Additional benefits include its hydraulic oil loop, which has been improved with upgraded technology, making it power-saving and rapid while ensuring stability and convenience during installation and maintenance of hydraulic elements, due to its removable and mobilizable oil tank.
The whole machine is controlled by computer, with the hydraulic system utilizing double proportional control. The machine has 40 sets of mould data memory, fault automatic alarms, and is highly automated with three operation modes "Manual", "Semi Auto", and "Full Auto" to choose from. Furthermore, the safety door of the machine is equipped with both electric and mechanical safety devices designed to ensure that no mould closing happens while the safety door is open, thereby making its operation safe and reliable. Lastly, the machine features two types of blowing functions of straight cutting and oblique cutting.
Technical Parameters:
| System |
Item |
Unit |
Basic Parameter |
|
Basic specifications
|
Applicable materials |
|
PE PP PVC PA… |
| Max product volume |
L |
10 |
| Number of heads |
SET |
1,2,3,4 |
|
Machine dimension
(LxWxH)
|
M |
4x2.3x2.5 |
| Machine weight |
TON |
8.2 |
| |
|
Mould clamping system
|
Mould clamping force |
KN |
150 |
| Platen opening strokes |
MM |
220-620 |
| Plate stroke |
MM |
540 |
| Max mould sizes(WxH) |
MM |
520x460 |
| |
|
Extrusion system
|
Screw diameter |
MM |
80 |
| Screw slenderness ratio |
L/D |
24 |
| Plasticizing ability (HDPE) |
KG/H |
90 |
| Screw heating stage/zone |
Zone |
4 |
| Screw heating power |
KW |
15.85 |
| Screw fan power |
KW |
0.28 |
| Extrusion motor power |
KW |
30 |
| |
|
|
Head
|
Head heating stage/zone |
Zone |
3 |
| Head heating power |
KW |
10 |
| |
|
Energy consumption
|
Total machine power |
KW |
80 |
| Oil motor power |
KW |
18.7 |
| Air pressure |
MPA |
0.6-0.8 |
| Compression air volume |
M3/min |
1.5 |
| Cooling water volume |
L/min |
40 |
Applications:
One of the many applications of the MEPER 80D is the production of milk bottle packing bottles. With its 4 cavity blow moulding capabilities, it can easily produce large quantities of high-quality bottles in a short amount of time. Its toggle type clamping system ensures that each bottle is consistent in shape and size, making it ideal for businesses looking to maintain a consistent brand image.
The MEPER 80D is also a great choice for businesses in need of a 5 gallon blow molding machine. Its ability to produce large containers with ease and precision makes it a valuable asset to any business. With customizable color options available, businesses can choose to produce containers that match their branding or desired aesthetic.
The minimum order quantity for the MEPER 80D is 1 set, and pricing is negotiable depending on the needs of the business. Standard export packaging ensures that the product arrives safely and securely, and delivery time is estimated at 25-35 work days. Payment can be made through L/C or T/T, and the product has a supply ability of 100 sets per month.
Support and Services:
The Automatic Blow Moulding Machine is a high-tech equipment used in the production of plastic containers. Our product technical support and services include:
- Installation and commissioning
- Training and technical support for operation and maintenance
- Regular maintenance and inspection services
- Repair and replacement of parts
- Upgrades and customization services
- 24/7 technical support hotline
Packing and Shipping:
Product Packaging:
- The automatic blow moulding machine is packed in a sturdy wooden crate to ensure safe transportation.
- The machine is securely fastened inside the crate with foam padding to prevent any damage during shipping.
- The crate is labeled with the product name, model number, and handling instructions for easy identification.
Shipping:
- The automatic blow moulding machine is shipped via freight carrier.
- Shipping rates are calculated based on the destination and weight of the machine.
- Once the machine is shipped, the customer will receive a tracking number to monitor the shipment.
- The estimated delivery time will depend on the customer's location and shipping method selected.
FAQ:
Q: What is the brand name of this Automatic Blow Moulding Machine?
A: The brand name of this machine is MEPER.
Q: What is the model number of this machine?
A: The model number of this machine is 80D.
Q: Where is this machine made?
A: This machine is made in China.
Q: Does this machine have any certification?
A: Yes, this machine has CE/ISO9001:2008 certification.
Q: What is the minimum order quantity for this machine?
A: The minimum order quantity for this machine is 1 set.
Q: What is the price of this machine?
A: The price of this machine is subject to negotiation.
Q: What are the packaging details for this machine?
A: The machine is packaged in a standard export package.
Q: How long does it take for delivery?
A: The delivery time is 25-35 work days.
Q: What are the payment terms for this machine?
A: The payment terms for this machine are L/C and T/T.
Q: What is the supply ability of this machine?
A: The supply ability for this machine is 100 sets per month.
