Product Description:
The MP plastic blow molding machine is designed to process various types of high molecular plastic hollow products. This versatile machine can be used to produce hollow products ranging from 5 milliliters to 100 liters in size. The products that can be made with this machine are extensive, including bottles, pots, jars, barrels, toys, tool boxes, bed boards, desk boards, chairs, and even automotive parts.
In addition, the MP plastic blow molding machine can blow different materials, including PE, PP, PVC, PA, PC, PS, and EVA. Its advanced technology allows it to provide the perfect process for each material, ensuring that the finished product meets the highest standards of quality and consistency.
Features:
The extruding device is equipped with a variable frequency motor, which satisfies the rotational requirements of the screw during the blowing process. Moreover, by using screws with a high slenderness ratio, the device can process various materials while demonstrating high production and low energy consumption. The barrel of this device further consists of a resistance heater that is computer-controlled, ensuring quick, stable, and even heating.
In addition, achieving different product designs is possible with the installation of a different head in the combined extrusion system between two other machines. For instance, the device can blow products with single or double layers, both featuring a view strip line.
The mould clamping device of this machine adopts vertical compression, three pilot post, a big beam arm and linear guiders, cylinder spindle and double working position. The molds move quickly and steadily, ensuring high efficiency.
This machine incorporates an improved hydraulic oil loop design that is power-saving, rapid, and stable. The hydraulic elements of the machine are easily installable and maintainable with the oil tank, which is both removable and mobilizable.
The machine is entirely computer-controlled, with its hydraulic system incorporating a double proportional control scheme. It features a fault automatic alarm, high automation, and can memory up to 40 sets of moulds. Additionally, the machine presents three different operation modes - Manual, Semi Auto, and Full Auto - for users to choose from.
Notably, the machine's safety door adopts electric and mechanical safety devices, which prohibit operations when the safety door opens. Also, with two blowing functions of straight cutting and oblique cutting, the functionality of this machine is versatile and adjustable to meet specific production needs.
Technical Parameters:
technical parameters
| System |
Item |
Unit |
Basic Parameter |
|
Basic specifications
|
Applicable materials |
|
PE PP PVC PA… |
| Max product volume |
L |
10 |
| Number of heads |
SET |
1,2,3,4 |
|
Machine dimension
(LxWxH)
|
M |
4x2.3x2.5 |
| Machine weight |
TON |
8.2 |
| |
|
Mould clamping system
|
Mould clamping force |
KN |
150 |
| Platen opening strokes |
MM |
220-620 |
| Plate stroke |
MM |
540 |
| Max mould sizes(WxH) |
MM |
520x460 |
| |
|
Extrusion system
|
Screw diameter |
MM |
80 |
| Screw slenderness ratio |
L/D |
24 |
| Plasticizing ability (HDPE) |
KG/H |
90 |
| Screw heating stage/zone |
Zone |
4 |
| Screw heating power |
KW |
15.85 |
| Screw fan power |
KW |
0.28 |
| Extrusion motor power |
KW |
30 |
| |
|
|
Head
|
Head heating stage/zone |
Zone |
3 |
| Head heating power |
KW |
10 |
| |
|
Energy consumption
|
Total machine power |
KW |
80 |
| Oil motor power |
KW |
18.7 |
| Air pressure |
MPA |
0.6-0.8 |
| Compression air volume |
M3/min |
1.5 |
| Cooling water volume |
L/min |
40 |
Applications:
The MEPER Automatic Blow Moulding Machine 80D is a custom blow molding machine that is perfect for a variety of product application occasions and scenarios. With its 4 cavity blow moulding machine, this product is ideal for milk bottle packing bottle production and other similar applications.
Manufactured in China, the MEPER Automatic Blow Moulding Machine 80D meets the highest standards of quality and is certified with both CE and ISO9001:2008. It is available for purchase with a minimum order quantity of 1 set and the price is negotiable. The packaging details are standard export package and delivery time takes around 25-35 work days.
The 80D model is a versatile extrusion blow molding machine that can be used in a variety of scenarios. Its 4 cavity blow moulding capability makes it perfect for producing milk bottles and other similar products. Additionally, it can be customized to produce bottles in a range of different colors to fit your needs.
With a monthly supply capability of up to 100 sets, the MEPER Automatic Blow Moulding Machine 80D is a reliable choice for businesses looking to improve their production capabilities. The machine is equipped with Schneider contactors, ensuring that it is both safe and efficient to operate.
Whether you require a custom blow molding machine for your business or a 5 gallon blow molding machine for more specific applications, the MEPER Automatic Blow Moulding Machine 80D is the ideal choice. Order yours today and experience the efficiency and quality of this top-of-the-line product.
Support and Services:
- Installation and setup of the machine
- Training and education on how to use the equipment
- Regular maintenance and inspection of the machine
- Repair and replacement of parts as needed
- 24/7 technical support for any issues or concerns
We pride ourselves on providing excellent customer service and support to help our customers get the most out of their investment in our Automatic Blow Moulding Machine. Contact us today for more information on our technical support and services.
Packing and Shipping:
Product Packaging:
- The Automatic Blow Moulding Machine will be packed securely in a wooden crate to prevent any damage during transit.
- All necessary accessories and components will be included in the crate.
- The crate will be clearly labeled with the product name and any handling instructions.
Shipping:
- The Automatic Blow Moulding Machine will be shipped via a reliable and trusted courier or freight company.
- Shipping will be arranged promptly after payment has been received.
- The customer will be provided with a tracking number and updates on the shipping status.
- Shipping times may vary depending on the destination and any customs requirements.
FAQ:
Q1: What is the brand name of the blow moulding machine?
A1: The brand name of the machine is MEPER.
Q2: What is the model number of the blow moulding machine?
A2: The model number of the machine is 80D.
Q3: Where is the blow moulding machine manufactured?
A3: The machine is manufactured in China.
Q4: Does the blow moulding machine have any certifications?
A4: Yes, the machine is CE/ISO9001:2008 certified.
Q5: What is the minimum order quantity for the blow moulding machine?
A5: The minimum order quantity for the machine is 1 set.
Q6: What is the price of the blow moulding machine?
A6: The price of the machine is negotiable.
Q7: How is the blow moulding machine packaged for shipping?
A7: The machine is packaged in a standard export package.
Q8: What is the delivery time for the blow moulding machine?
A8: The delivery time for the machine is 25-35 work days.
Q9: What are the payment terms for purchasing the blow moulding machine?
A9: The payment terms for purchasing the machine are L/C and T/T.
Q10: What is the supply ability for the blow moulding machine?
A10: The supply ability for the machine is 100 sets per month.
