Multi Cavity Fully Automatic PETG MP55D-2 Extrusion Blow Molding Machine For Production

Large Image : Multi Cavity Fully Automatic PETG MP55D-2 Extrusion Blow Molding Machine For Production

Product Details:

Place of Origin:	NINGBO,CHINA
Brand Name:	MEPER
Certification:	CE/ISO9001:2008
Model Number:	MP55D-2

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Packaging Details:	Wooden pallet(Standard) Wooden case(Optional)
Delivery Time:	25-55 Work Days
Payment Terms:	L/C, T/T

Contact Now

Detailed Product Description

Container Capacity:	5ml-1L	Applicable Material:	PETG
Multi-layer:	Yes	Multi-cavity:	Yes
PLC:	Techmation	Fully Automatic:	Yes
Highlight:	PETG Extrusion Blow Molding Machine , Multi-cavity extrusion moulding machine , Fully Automatic extrusion moulding machine

Blow Molding Machine Fully Automatic MP55D-2 for PETG Disinfectant Products

Types of Extrusion Blow Molding Machines:

Continuous Extrusion Blow Molding
- The parison is continuously extruded while molds move in and out to form parts.
- Best for: High-volume production (e.g., water bottles, detergent containers).
Intermittent Extrusion Blow Molding
- The extruder stops while the parison is cut and blown.
- Best for: Thicker-walled products (e.g., fuel tanks, large containers).
Reciprocating Screw Extrusion Blow Molding
- Uses a screw that moves back and forth to control parison length.
- Best for: Precision parts with consistent wall thickness.
Accumulator Head Blow Molding
- Molten plastic is stored in an accumulator before being pushed out as a parison.
- Best for: Large, heavy-duty parts (e.g., industrial drums, automotive components).

PARAMETERS	MP55D-2 φ50
SPECIFICATIONS
material	PETG
MAX container capacity L	0.1
number of die Set	2
machine dimension(L×W×H) M	2.87×2.14×2.28
total weight Ton	3.5
CLAMPING
clamping force KN	30
platen opening strokes mm	120-350
toggle stroke mm	230
Max mould size(W×H) mm	360×300
EXTRUDER UNIT
screw diameter mm	50
screw L/D ratio L/D	30
(HDPE)plasticizing capacity kg/h	30
screw heating zone zone	4
screw heating power kw	7
fan power kw	0.28
extruder driving power kw	11
DIE HEAD
die head heating zone zone	6
power of die heating kw	5
ENERGY-CONSUMPTION
power of the electric motor kw	7.5
air pressure Mpa	0.6-0.8
total power of machine kw	30.78
average energy consumption kw	15
compression air consumption m3/min	1
cooling water consumption L/minv	30

Standard Features:

Auto Lubrication

Water Cooled Modular Blow Pin

Hot Wire Cutting

Positioning Hole For Quick Mold Change

Adjustable Die head

Linear Transducer

FRL(Filter Regulator Lubricator) for Pneumatic

Proportional Hydraulic System fro better control

Swing and Adjustable Extrusion Platform
