80KW Power Single Head 10 Liters Volume Meper Blow Molding Machine

80KW Power Single Head 10 Liters Volume Meper Blow Molding Machine
80KW Power Single Head 10 Liters Volume Meper Blow Molding Machine

Large Image :  80KW Power Single Head 10 Liters Volume Meper Blow Molding Machine

Product Details:
Place of Origin: China
Brand Name: MEPER
Certification: CE/ISO9001:2008
Model Number: 100 FD
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiate
Packaging Details: Standard export package, wooden pallet(standard) wooden case(optional)
Delivery Time: 25-35 work days
Payment Terms: L/C, T/T
Supply Ability: 100 sets per month
Detailed Product Description
Max Product Volume: 10L Number Of Heads: 1、2、3、4set
Compression Air Volume: 1.5M3/min Plate Stroke: 540mm
Max Mould Sizes(WxH): 520x460 Head Heating Power: 10KW
Total Machine Power: 80KW Applicable Materials: PE PP PVC PA
Highlight:

80KW Blow Molding Machine

,

Single Head Blow Molding Machine

,

10 Liters Volume Blow Molding Machine

Product Description:

Functions

The MP plastic blow molding machine is designed to process various types of plastic hollow products with high molecular structures. Its capability ranges from producing products with a volume of 5 milliliters to 100 liters. These products include a wide variety of items such as bottles, pots, jars, barrels, toys, toolboxes, bed boards, desk boards, chairs, and auto parts.
The machine is highly versatile and can process different materials such as PE, PP, PVC, PA, PC, PS, and EVA. It also guarantees perfect processing to ensure a finished product of the highest quality.
Major technical parameters


SystemItemUnitBasic Parameter





Basic specifications




Applicable materials PE PP PVC PA…
Max product volumeL10
Number of headsSET1,2,3,4

Machine dimension

(LxWxH)

M4x2.3x2.5
Machine weightTON8.2








Mould clamping system

Mould clamping forceKN150
Platen opening strokesMM220-620
Plate strokeMM540
Max mould sizes(WxH)MM520x460








Extrusion system


Screw diameterMM80
Screw slenderness ratioL/D24
Plasticizing ability (HDPE)KG/H90
Screw heating stage/zoneZone4
Screw heating powerKW15.85
Screw fan powerKW0.28
Extrusion motor powerKW30



Head

Head heating stage/zoneZone3
Head heating powerKW10






Energy consumption

Total machine powerKW80
Oil motor powerKW18.7
Air pressureMPA0.6-0.8
Compression air volumeM3/min1.5
Cooling water volumeL/min40

Applications:

The extrusion blow moulder is perfect for creating a wide range of products, from small containers to large bottles. The machine is designed to work with a variety of materials, including HDPE, LDPE, PP, PVC, and PETG, making it a versatile choice for any manufacturing operation.
The extrusion blow molding machine is ideal for use in a variety of industries, including the food and beverage industry, the pharmaceutical industry, and the cosmetics industry. It's also suitable for manufacturing products for the automotive and household goods sectors.
The MEPER 100 FD Extrusion Blow Molding Machine is easy to use and requires minimal maintenance, making it a cost-effective choice for any manufacturing operation. It has a maximum mould size of 520x460 and a maximum product volume of 10L, making it suitable for a wide range of applications.
The platen opening strokes of 220-620mm make it easy to create products of different sizes, while the screw fan power of 0.28KW and head heating power of 10KW ensure that the machine is powerful enough to handle even the most demanding manufacturing processes.
The machine comes with a standard export package, including a wooden pallet (standard) and a wooden case (optional), and has a delivery time of 25-35 work days. Payment terms include L/C and T/T, and the supply ability is 100 sets per month. The minimum order quantity is 1 set, and the price is negotiable.
Overall, the MEPER 100 FD Extrusion Blow Molding Machine is a versatile and reliable choice for any manufacturing operation looking to create high-quality products quickly and affordably.



Support and Services:

The Extrusion Blow Molding Machine product comes with comprehensive technical support and services to ensure optimal performance and longevity. Our team of experienced technicians is available to provide installation, training, and maintenance services. We also offer troubleshooting and repair services to resolve any issues that may arise. In addition, we provide spare parts and upgrades to keep your machine up to date and running smoothly. Our goal is to provide our customers with the highest level of support and service throughout the lifespan of their Extrusion Blow Molding Machine.



FAQ:

Here are some frequently asked questions about our Extrusion Blow Molding Machine:
Q: What is the brand name of the machine?
A: The brand name of the machine is MEPER.
Q: What is the model number of the machine?
A: The model number of the machine is 100 FD.
Q: Where is the machine made?
A: The machine is made in China.
Q: What certifications does the machine have?
A: The machine has CE and ISO9001:2008 certifications.
Q: What is the minimum order quantity for the machine?
A: The minimum order quantity for the machine is 1 set.
Q: What is the price of the machine?
A: The price of the machine is negotiable. Please contact us for more information.
Q: What are the packaging details for the machine?
A: The machine comes with a standard export package, which includes a wooden pallet. A wooden case is optional.
Q: What is the delivery time for the machine?
A: The delivery time for the machine is 25-35 work days.
Q: What are the payment terms for the machine?
A: The payment terms for the machine are L/C and T/T.
Q: What is the supply ability of the machine?
A: The supply ability of the machine is 100 sets per month.
